Triumph Sprint GT User Manual

57
How to Ride the Motorcycle
Braking
1. Front brake lever
1. Rear brake pedal
Triumph strongly recommends that all riders
take a course of instruction, which includes
advice on safe brake operation.
Warning
WHEN BRAKING, OBSERVE THE
FOLLOWING:
Close the throttle completely, leaving the
clutch engaged to allow the engine to help
slow down the motorcycle.
Shift down one gear at a time such that the
transmission is in first gear when the
motorcycle comes to a complete stop.
When stopping, always apply both brakes
at the same time. Normally the front brake
should be applied a little more than the
rear.
Shift down or fully disengage the clutch as
necessary to keep the engine from stalling.
Never lock the brakes, as this may cause
loss of control of the motorcycle and an
accident.
2
1
3
4
1
jaim
Warning
For emergency braking, disregard
downshifting, and concentrate on applying
the front and rear brakes as hard as
possible without skidding. Riders should
practice emergency braking in a traffic-free
area. (See ABS warnings below/over.)
Incorrect brake technique could result in
loss of control and an accident.
1
ceyr

Triumph Sprint GT Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050 cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Fuel Tank Capacity	20 litres
Max Power	130 PS (95.6 kW) @ 9, 200 rpm
Max Torque	108 Nm @ 6, 300 rpm
Exhaust	Stainless steel 3 into 1
Frame	Aluminium beam
Front Suspension	43mm
Rear Suspension	Monoshock with adjustable preload and rebound damping
Front Brakes	Twin 320 mm floating discs, Nissin 4-piston calipers
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper
Seat Height	815mm
Ignition	Digital inductive type
Swingarm	Single-sided, aluminium alloy
Wheelbase	1, 537 mm
