Page #110 background image
C-16
REPLACEMENT PARTS
Figures C-2 through C-6 show the replaceable parts of the Model
3430 gauge.
GAUGE ASSEMBLY
Match the reference number (Ref #) shown below with the correct
part in Figure C-2 on the opposite page.
Ref #
Part Number
Description
Qty
1
000001.0601
Washer #6 INT Lock SS
4
2
106368
3430 Gauge Gasket (topshell to base)
1
3
105299
3430/3440 Preamplifier Assembly
1
4
106340
Gasket, Depth Strip Hole
1
5
104149
3430 Battery Assembly (w/case)
1
6
105298
High Voltage Cover Box
1
7
100989
Gasket-Molded for Base Post
1
8
106068
3430 Topshell
1
9
105300
3430 Nameplate
1
10
104122
Radiation Label
1
11
000900.0621
Screw, #4 (.114 Dia.) x 3/16" Drive
8
12
000310.4891
Screw, 6-32 x 5/8 SHCS w/ Insert
4
13
105301
3430 Front Panel Assembly
1
14
102662
Scaler Label (3401-3411)
1
15
101603.1010
Roll Pin, 3/32 D X 5/8 L (Index Rod Top)
1
16
106367
Gasket, Flat Tower (do not use on old
1
topshell)
17
018128.0001
Loctite, 290 Wick & Seal
18
102096
3400 Cap Screw
1
19
102103
Cap Screw Bumper
1
