C-22
SCALER ASSEMBLY
Match the reference number (Ref #) shown below with the correct
part in Figure C-6 on the opposite page.
Ref #
Part Number
Description
Qty
1
105291
Charger Well
1
2
106819
3430 Overlay-w/inserts
1
3
105287
Front Panel 3430
1
4
106369
Front Panel Gasket
1
5
105832
PCB, Assembly, 3430 CPU
1
6
105294
Washer
2
7
102888
Cable, 3400B (front panel to base)
1
8
105295
Nut
1
9
106525
Assembly, Metal Cap w/lug
1
10
000001.0401
Washer, #4 Int. Lock SS
5
11
000204.1400
Screw, 4-40 x 1/4 PHMS Phil SS
4
12
000202.1400
Screw 4-40 x 1/8 PHMS Phil SZP
1
13
106856
Grounding Clamp
1
14
000204.2408
4.40 x 1/4 PHMS Slotted Nylon
1
15
000012.0406
# 4 Flat Washer Nylon
1
