Troxler 3430 User Manual

B-6
MECHANICAL SPECIFICATIONS
Base Cast Aluminum
Gauge Size (w/o handle) 14.45 × 8.85 × 6.45 in
367 × 225 × 164 mm
Gauge Height (w/ handle) 23.25 in (591 mm) for 12" rod
19.25 in (489 mm) for 8" rod
Transportation Case 29.5 × 14.0 × 17.0 in
74.9 × 35.6 × 43.2 cm
Weight 29 lb (13 kg)
Shipping Weight 86 lb (39 kg)
Operating Temperature Ambient: 14 to 158 °F
–10 to 70 °C
Surface: 350 °F
175 °C
Storage Temperature –70 to 185 °F
–55 to 85 °C
Vibration Test 0.1 in (2.54 mm) at 12.5 Hz
Drop Test 300 mm onto 25 mm steel ball

Troxler 3430 Specifications

General

Measurement Principle	Nuclear
Power Source	Rechargeable battery
Display	LCD
Data Storage	Internal memory
Type	Portable
Material Measured	Soil, Asphalt
Moisture Measurement Range	0 to 60%
Operating Temperature	-10 to 50°C
Source	Cesium-137
