Troxler 3430 User Manual

Model 3430
3-1
CHAPTER 3
OPERATING THE GAUGE
This chapter explains the basic operation of the Model 3430 Surface
Moisture-Density Gauge. Instructions for conducting a daily gauge
inspection, setting gauge parameters, taking the daily standard
count, preparing the site, positioning the gauge, and taking moisture
and density measurements are included.
CONTENTS
The Keypad .................................................................................... 3-2
Source Rod Positions ..................................................................... 3-4
Daily Inspection ............................................................................. 3-5
Turning the Gauge On ................................................................... 3-6
Gauge Parameter Setup .................................................................. 3-7
Setting Measurement Units ..................................................... 3-7
Setting the Count Time ........................................................... 3-8
Setting the Depth ..................................................................... 3-8
Selecting the Mode (Marshall/Proctor) ................................... 3-8
Taking the Standard Count .......................................................... 3-10
Site Preparation/Gauge Positioning ............................................. 3-12
Soil and Base Course Preparation ......................................... 3-12
Asphalt Surface Preparation .................................................. 3-14
Taking a Measurement – Soil Mode ............................................ 3-15
Taking a Measurement – Asphalt Mode ...................................... 3-17
GAUGE OPERATION

Troxler 3430 Specifications

General

Measurement Principle	Nuclear
Power Source	Rechargeable battery
Display	LCD
Data Storage	Internal memory
Type	Portable
Material Measured	Soil, Asphalt
Moisture Measurement Range	0 to 60%
Operating Temperature	-10 to 50°C
Source	Cesium-137
