Appendix C–4
MECHANICAL SPECIFICATIONS
Size 162.6 H x 71.1 D x 68 W cm
(64 H x 28 D x 26.75 W in.)
Weight Approximately 227 kg (500 lb)
Shipping Weight (est.) 328.8 kg (725 lb)
Unit with Packaging
Shipping Weight, (est.) 487.6 kg (1075 lb)
with All Accessories
Mold Weight 11.6 kg (25.5 lb)
Puck Weight 3 kg (6.6 lb)
Compaction Pressure 200 – 1000 kPa (29 – 145 psi)
Pressure Accuracy Meets or exceeds FHWA
specifications
Number of Gyrations Adjustable from 1 – 999
Angle of Gyration 0.00 – 3.0 0.02 degrees
Internal or external
Mold Dimensions 150 mm ID x 317.5 mm height
(100 mm and 4 in. ID also available)
50.0 mm minimum specimen height
Maximum Mold 175 C (350 F)
Temperature
Speed of Gyration 30 ± 0.5 gyrations/minute
Hydraulic Oil Light grade (ISO VG 32, SAE 10)
hydraulic oil
