2–6
A list of compatible USB memory devices and printers is
available on the 5850v2 product page on Troxler’s
website at www.troxlerlabs.com.
The output data can be formatted either in a height-versus-gyration
table format or in a full table format which includes the height, ram
pressure, gyration angle, and gyration rate for each gyration.
To automatically output gyration versus height data, connect the
compactor to the computer or printer and turn on the Auto Output
option as described on page 3–11.
NOTE
Before outputting data to a printer or computer, ensure
that the Model 5850v2 is properly connected to the
output device.
COMPACTING A SPECIMEN
WARNING
To prevent personal injury or equipment damage,
before operating the Model 5850v2 Gyratory
Compactor, become familiar with the safety
warnings on page 1–1.
The following is a checklist for compacting an asphalt specimen
with the Model 5850v2 Gyratory Compactor. Each step is discussed
in detail in the following sections.
1
1
.
.
Set up the gyratory compactor.
2
2
.
.
Clean the mold tray, ram head, lower carriage, upper carriage
assembly, and upper puck plate.
3
3
.
.
Lubricate the ram head and upper puck plate with Magnalube-
G.
