Troxler 5850v2 - General Maintenance Schedule

Appendix A–4
GENERAL MAINTENANCE SCHEDULE
The following sections provide a recommended schedule for
performing regular maintenance on the Model 5850v2 Gyratory
Compactor.
CAUTION
Do not use a degreasing cleaner or glass cleaner to clean
the clear chamber door. To prevent damage to the door
surface, use a mild detergent only.
NOTE
Use any degreasing cleaner and a clean rag to clean
metal parts. See the safety warnings on page 1–1.
DAILY, BEFORE USE
1
1
.
.
Vacuum the mold tray and compaction chamber.
2
2
.
.
Clean the mold tray, lower carriage plate (including the mold
positioning pins), and ram head (see Figure 2–2, View A, on
page 2–9), as well as the upper carriage assembly and upper
puck plate (View B) with Bindoff or similar cleaner.
3
3
.
.
Clean the mold and pucks with Bindoff or similar cleaner.
BEFORE EACH CYCLE
1
1
.
.
If necessary, clean the mold tray, lower carriage plate (including
the mold positioning pins), and ram head (see Figure 2–2,
View A, on page 2–9), as well as the upper carriage assembly
and upper puck plate (View B) with Bindoff or similar cleaner.
2
2
.
.
Ensure that the exterior surface of the mold is free of dirt and
asphalt residue.
3
3
.
.
Lubricate the ram head with Magnalube-G.
4
4
.
.
Inspect the upper puck plate. If dry, lubricate it with
Magnalube-G.
