XRS2 and SRS2 EID Stick Reader
Issue 5, 03/2018
47
The case spare part changed in December 2017. See
Changes to the product
on page 22.
Before replacing an EID Stick Reader case, ascertain that you have a
new
case spare part and not an
old one. The new spare part is supplied with case front and rear together as one spare part. The new
case front has a different screw boss and the new case rear has a manufacturing date of January
2018 or subsequent.
See the technical bulletin 18-007 “XRS2 and SRS2 Stick Reader - Change to
spare parts: main battery and case” for details.
E
ven if only one half of the case is damaged and requires replacement, it is important that both case
halves are replaced in order to provide an effective seal.
1 O
pen the case. See page 30.
2 Remove all internal components:
3 Check the spare part to make sure you have the correct case for the XRS2 or SRS2 model:
SRS2 EID Stick Reader:
X
RS2 EID Stick Reader:
4 Refit all internal components into the new case front.
5 Replace the case rear. Check that the vent label is attached to the spare part. This is essential in providing a
good seal.
