About Your Ice Machine & Installation Requirements (cont.)
TI-430/530/630
Front Rear
Left Right
Top Bottom
Dimensions may vary by ± 1/8" (3.2 mm)
30-3/16"
(767 mm)
11-3/16"
(284 mm)
13-5/8"
(346 mm)
7/8"
(22 mm)
22-3/16"
(563 mm)
2-9/32"
(58 mm)
23-3/32"
(587 mm)
24-11/16"
(627 mm)
Water Outlet
3/4" FNPT
Water Inlet
1/2" FNPT
8-11/16"
(220 mm)
3-1/32"
(77 mm)
2-29/32"
(74 mm)
19-7/32"
(488 mm)
9-27/32"
(250 mm)
11-3/4"
(298 mm)
1-1/16"
(27 mm)
1-1/16"
(27 mm)
1-1/32"
(26 mm)
1-15/32"
(37 mm)
Ice Level
Sensor
Ice Drop Zone
