Installation & Setup (cont.)
Remote Monitoring
Press Remote Monitoring
to access the Remote Monitoring QR Code. Follow instructions on the remote monitoring website. See fig. 1.
Fig. 1. Remote monitoring screen displays.
Fig. 2. The green icon (A) and the red icon (B).
For more information, visit connect.truemfg.com
The color of the remote monitoring icon indicates the current status of the remote monitoring. See fig. 2.
Green: Connected Red: No cell signal, no RS485, or no power
BA
Dispenser Bracket
Follow the dispenser unit, adapter kit, or top kit instructions for securing the ice machine. If no instructions are available, secure the ice
machine with the provided mounting brackets.
1. Rotate the mounting brackets so that they fit flush to the dispenser unit.
2. Secure the mounting brackets to the ice machine with the bolts provided.
3. Secure the mounting brackets to the dispenser unit with self-tapping screws (not provided).
NOTICE ›
Avoid damage to dispenser unit components when attaching the mounting brackets.
USER ACTION!
Ice level management is recommended to prevent water leakage or movement of ice machine during agitation. See "Ice Level
Sensor Setup" (pg. 33).
