True ICE User Manual

TRUE ICE truemfg.com
TEC_TM_171 | REV. G | EN
P#224534
02/28/2024 Page 30 of 72
Installation & Setup (cont.)
Ice Storage Bin or Dispenser (cont.)
Fig. 3. A 22" ice machine mounted left (A) and right (B) on a 30" bin with a bin adapter.
Fig. 5. Ice bins with (A) and without (B) a drop-zone deflector.
Fig. 4. Installed drop-zone deflector side view.
BA
BA
Bin Adapters
Bin adapters cover the opening when the ice storage bin is wider than the ice machine. See examples of possible configurations below. To
purchase, contact TRUE Parts Department at 800-424-8783 or PartsInquiries@TrueMFG.com.
Bin Bin
Ice
Machine
Ice
Machine
Ice
Machine
Ice
Machine
Bin
Bin Adapter Bin Adapters
Fig. 1. Ice machine on one side of
the bin.
Fig. 2. Ice machines installed on both sides of the bin. Fig. 3. Ice machine centered on the bin.
Bin Adapter
