TSC ME240 User Manual

5
1.6 Media Specifications
Media Specifications
203 dpi models
300 dpi models
Label roll capacity
203.2 mm (8”) OD
Media alignment
Edge alignment
Media type
Continuous, die-cut, black mark, fan-fold, notch
Media wound type
Printing face outside wound
Media width (label +
liner)
Max. 118 mm (4.6”)
Min. 25.4 mm (1.0”)
Media thickness (label
+ liner)
Max. 0.28 mm (11 mil)
Min. 0.06 mm (2.36 mil)
Media core diameter
25.4 mm~76.2 mm (1”~3”)
Label length
5~2,286 mm (0.2”~90”)
5~1,016 mm (0.2”~40”)
Label length (peeler
mode)
Max. 152.4 mm (6”)
Min. 25.4 mm (1”)
Label length (cutter
mode)
Max. 2,286 mm (90”)
Max. 1,016 mm (40”)
Min. 25.4 mm (1”)
Min. 25.4 mm (1”)
Gap height
Min. 2 mm
Black mark height
Min. 2 mm
Black mark width
Min. 8 mm (0.31”)

TSC ME240 Specifications

General

Resolution	203 dpi / 300 dpi
Operating Temperature	5°C to 40°C (41°F to 104°F)
Print Method	Thermal Transfer & Direct Thermal
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Humidity	20% to 85% RH (non-condensing)
