TSC ME240 User Manual

3
Text, bar code, graphics/image printing (Please
refer to the TSPL/TSPL2 programming manual for
supporting code page)
Supported bar code
Supported image
1D bar code
2D bar code
BITMAP,
BMP,
PCX
(Max. 256 colors
graphics)
Code 39,
Code 93,
Code128UCC,
Code128 subsets
A.B.C, Codabar,
Interleave 2 of 5,
EAN-8, EAN-13,
EAN-128,
UPC-A,
UPC-E,
EAN and UPC 2(5)
digits add-on,
MSI,
PLESSEY,
POSTNET,
China POST,
GS1 DataBar,
Code 11,
Logmars
PDF-417,
Maxicode,
DataMatrix,
QR code,
Aztec
○
○
1.2.2 Printer optional features
The printer offers the following optional features.
Product option feature
User
options
Dealer
options
Factory
options
LCD display (graphic type, 128x64 pixel)
with back light (for basic model only)
-
-
○
Internal Ethernet print server (10/100 Mbps)
interface
-
-
○
USB host (Support PC keyboard and bar
code scanner)
-
-
○
Centronics interface
-
-
○
Peel-off module
-
○
-
Cutter module
Paper thickness: 0.06~ 0.19mm, 500,000 cuts
0.20~ 0.25mm, 200,000 cuts
Note:
Except for the linerless cutter, all
regular/heavy duty/care label cutters DO NOT
cut on media with glue.
-
○
-
Bluetooth module (RS-232C interface)
○
-
-
KP-200 Plus keyboard display unit
○
-
-
KU-007 Plus programmable smart keyboard
display unit
○
-
-
HCS-200 long rang CCD scanner
○
-
-

TSC ME240 Specifications

General

Resolution	203 dpi / 300 dpi
Operating Temperature	5°C to 40°C (41°F to 104°F)
Print Method	Thermal Transfer & Direct Thermal
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Humidity	20% to 85% RH (non-condensing)
