6.2 Mechanism Fine Adjustment to Avoid Ribbon Wrinkles
This printer has been fully tested before delivery. There should be no ribbon wrinkle presented on
the media for general-purpose printing application. Ribbon wrinkle is related to the media thickness,
print head pressure balance, ribbon film characteristics, print darkness setting…etc. In case the
ribbon wrinkle happens, please follow the instructions below to adjust the printer parts.
Adjustable
Printer
Parts
Symptom
1. Wrinkle happens from label lower left
to upper right direction (“ˊ”)
2. Wrinkle happens from label lower right
to upper left direction (“ˋ”)
Wrinkle
Example
Feed direction
