TSC ME240 User Manual

58
3.3 Diagnostics
Diagnostics
Exit
Print Config.
Dump Mode
Rotate Cutter
3.3.1 Print Config.
This feature is used to print current printer configuration to the label. On the configuration
printout, there is a print head test pattern, which is useful for checking if there is any dot
damage on the print head heater element. (Please refer to section 4.2.)
Diagnostics 1/4
Self Test …
Printing …
>
Print Config.
1/1
Dump Mode
Rotate Cutter
3.3.2 Dump Mode
Captures the data from the communications port and prints out the data received by printer. In
the dump mode, all characters will be printed in 2 columns as following. The left side
characters are received from your system and right side data are the corresponding
hexadecimal value of the characters. It allows users or engineers to verify and debug the
program. (Please refer to section 4.2)
Diagnostics 2/4
Printing …
Dump Mode
Pritn Config.
1/1
>
Dump Mode
Rotate cutter
Note:
1. Dump mode requires 4” wide paper width.
2. Turn off / on the power to resume printer for normal printing.
3. Press FEED button to back to the previous menu.
3.3.3 Rotate Cutter

TSC ME240 Specifications

General

Resolution	203 dpi / 300 dpi
Operating Temperature	5°C to 40°C (41°F to 104°F)
Print Method	Thermal Transfer & Direct Thermal
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Humidity	20% to 85% RH (non-condensing)
