TSC ME240 - Installation of Ribbon; Loading the Ribbon

14
2.5 Installation of Ribbon
2.5.1 Loading the Ribbon
1. Open the printer right side cover.
2. Install the ribbon and paper core onto the
ribbon supply spindle and ribbon rewind
spindle. Push the paper core and ribbon
roll to the end of the spindle.
3. Push the print head release lever to open
the print head mechanism.
