2.6.3 Loading the Media in Peel-off Mode (Option)
1. Open the peel-off cover by pulling-down the tabs located on peel-off cover.
2. Refer to chapter 2.6.1 to install the label.
3. Use the DiagTool to set the media sensor type and calibrate the selected sensor.
(Please refer to chapter 4.)
4. Pull the label through the front of the printer and take some labels off only leave the liner.
5. Feed the liner into peel-off cover slot.
Liner
Label
Slot
Liner
Label
