21
2.6.2 Loading the Fan-fold Label
Fan-fold media feeds through rear external label entrance chute.
1. Open the printer right side cover.
2. Push the print head release lever to open the print head mechanism.
3. Move the label roll guard horizontally to the end of label spindle then flip down the label
roll guard.
4. Remove the 3 inch core adapters from the
media supply spindle.
5. Insert the fan-fold media through the rear external label entrance chute.
6. Pull fan-fold label leading edge forward through the media guide bar, media sensor and
place the label leading edge onto the platen roller.
7. Adjust the label roll guard and label guide by sliding to fit the paper width.
8. Close the print head mechanism making sure the latches are engaged securely.
9. Set the media sensor type and calibrate the selected sensor. (Please refer to section 4)
Note:
Please calibrate the gap/black mark sensor when changing media.
