TSC ME240 - Page 20

15
4. Thread the ribbon leader through the slot
between ribbon sensor and ribbon guide
bar until ribbon passes through the print
head and place the ribbon leader onto the
ribbon rewind spindle.
5. Stick the ribbon leader onto the paper
core. Keep the ribbon flat and without
wrinkle.
6. Rotate the ribbon rewind spindle until the
ribbon leader is thoroughly, firmly
encompassed by the black section of the
ribbon.
Ribbon sensor
Ribbon guide bar
Ribbon leader
