29
29
PEX-1000 Series
Print
Engine Service Manual
6. Put back the golden color screw, and turn it in the clockwise direction to fix the screw.
Left-handed configuration:
Right -handed configuration:
7. Pushing the peel-off roller module upward.
Left-handed configuration
Right -handed configuration
