TSC TTP-245 User Manual

30
7. Specifications
7.1 Printer Specifications
Item TTP-245 TTP-343
Mechanism
Resolution 203 dpi 300 dpi
Max. Print Width 108 mm 104 mm
Max. Print Length 1000 mm ( 39” ) 420 mm (16.53”)
Ribbon Capacity 300 meter with 1” core (Max. OD 67 mm)
Printing Speed 2, 3, 4 and 5 ips 2, 3 ips
Peeler function 2, 3 ips 2 ips
Printing Method Direct thermal and thermal transfer printing.
Enclosure
Structure
Dimension
Operation Panel
Double-walled plastic.
Standard Model: 314mm(L) x 213mm(W) x 188mm(H)
One push switch, and one indicator LED (Green,
Orange, Red colors).
Hardware
Sensor Transmissive sensor (offset 6 mm from liner
edge).
Reflective sensor (position adjustable).
Head open micro switch.
Ribbon end sensor
Memory 2M byte Flash memory
2M bytes DRAM
Interface RS-232C (max baud rate, 19,200 bps).
USB: V1.1.
Centronics.
Power AC input: 100-240V universal auto switching power
supply.
DC output: 24V 3.75A.
Firmware
Font Type 8 alpha-numeric bitmap fonts, and 1 true type font.
Rotation 0, 90,180 and 270 degrees.
Barcode Format
1D Bar code
Code 39, Code 93, Code 128UCC, Code128 subsets
A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13,
EAN-128, UPC-A, UPC-E, EAN and UPC2(5) digits

TSC TTP-245 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm (4.25")
Max Print Speed	5 inches per second
Interface	Parallel
Ribbon Capacity	300 meters
Label Width	1 to 4.4 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Print Length	39.37 inches (1000 mm)
Label Thickness	0.08 to 0.2 mm
