TSC TTP-245 User Manual

31
add-on, MSI, PLESSEY, POSTNET, ChinaPOST,
ITF-14, EAN-14.
2D Bar code
PDF-417, Maxicode, and DataMatrix, QR CODE.
Command Set TSPL2
Environment
Operation
Temperature: 5℃ ~ 40℃.
Relative Humidity: 25% ~ 85% (Non Condensing).
Storage
Temperature: -40℃ ~ 60℃.
Relative Humidity: 10% ~ 90% (Non Condensing).
7.2 Label Stock Specifications
Item Specification
Type Label (Continuous , Die-cut , Fan-fold).
Wound Type Outside wound.
Width 20mm ~ 112mm (0.78” ~ 4.4”).
Length 10mm ~ 1000mm (0.4” ~ 39”).
25.4mm ~ 1000mm (1” ~ 39”).(for peeler and cutter)
Thickness 0.06mm ~ 0.19mm. (2.3~7.4 mil), max. 150g/m
2
Roll Diameter 5”.
Roll Core Diameter 25.4mm ~ 76.2mm (1” ~ 3”).
Gap Height 2mm min.
Black Mark Height 2mm min.
Black Mark Width 8mm min.
7.3 Ribbon Specifications
Item Specification
Type Wax, Wax / Resin, Resin.
Core Diameter 1".
Width Max 110mm.
Capacity 300m with 1" core.
Wound Type Outside wound.
Ribbon End Clear or silver end tape.

TSC TTP-245 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm (4.25")
Max Print Speed	5 inches per second
Interface	Parallel
Ribbon Capacity	300 meters
Label Width	1 to 4.4 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Print Length	39.37 inches (1000 mm)
Label Thickness	0.08 to 0.2 mm
