TSC TTP-245 User Manual

35
Update History
Date Content Editor
2006/8/15 1. Modify to RoHS version. Camille Pao
2006/9/25 1. Modify power on utilities section.
2. Modify LED and button operation section.
Camille Pao
2006/11/30 1. Modify power on utilities section. Camille Pao
2007/1/25 1. Modify 3.5 section. Camille Pao
2007/4/14 1. Update TSC e-mail address
2. Update 5.5 section: maintenance
Camille Pao

TSC TTP-245 Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Processor	32-bit RISC CPU
Max Print Width	108 mm (4.25")
Max Print Speed	5 inches per second
Interface	Parallel
Ribbon Capacity	300 meters
Label Width	1 to 4.4 inches
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
Power Supply	External Universal Switching Power Supply
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Operating Humidity	25% to 85% non-condensing
Print Length	39.37 inches (1000 mm)
Label Thickness	0.08 to 0.2 mm
