25
3.3. Replacing Lower Cover
1. Refer to 3.1 to open the top cover.
2. Remove the 6 screws of lower inner cover. Turn the printer upside down, and
remove the 2 screws of hinge holder, 1 screw of memory card cover.
Screws
Screws
2 screws of hinge holder
Screw of memory
card cover
