3.15. Loading the Label in Peel-off Mode
Note: Both thermal paper and plain paper apply for peel-off function but
neither PVC nor vynle work at peel-off function.
1. Insert a 1” label spindle into a paper roll.
2. Open the printer top cover by pushing forward the top cover open levers. The top
cover support will hold the printer top cover.
3. Install the paper roll on the paper roll mount.
4. Open the peel-off panel by pulling it out.
To Next Page
