3.12. Replacing Feed Button and Fee
d Button PCB
1.
Please refer to 3.1 for disassembling the top cover and top inner cover
.
2.
T
urn the top cover upside dow
n.
3.
Screw of
f 2 screws on
feed button PCB
and
remove feed button P
CB.
4.
Use a flat head driver to poke up the
feed button
.
5.
Reassemble parts in r
everse procedures.
Screws
T
op Cover
Feed Button PCB
40
42
