25
TROUBLESHOOTING
YES
Replace the comm wire between Sage
and Phoenix (red, orange, yellow,
black cable). Did this resolve the
issue?
Cycle power. Does the F10 reappear
after approxiamately 5 seconds?
Replace the I/O control
board (SAGE). If the
problem persists, replace
the touch screen-display
assembly.
NO
NO
Contact factory for troubleshooting.
Troubleshooting:
F10: Communication Failure
Troubleshooting:
F12: Firmware Reboot
Return the oven
to service.
