TurboChef Double Batch

A-5
APPENDIX  REPLACING OVEN COMPONENTS
Figure
Reference #
Item Description Item Part Number Fastener Description Fastener Part Number(s)
1 Bumper, Round
105047
(qty 2 per door)
N/A N/A
2 Door Kit (Glass/Frame)
HHD-8377
(qty 1 per door)
Screw, 6-32 X .38 PFH 100 Deg, SS 101430 (qty 8 per door)
3 Gasket, Door
HHD-8236
(qty 1 per door)
N/A N/A
4 Handle, Door
HHD-8383
(qty 1 per door)
RTV Sealant, Hi-temp, Gray, 600F, #82195 105024
5 Hinge, Left
HHD-8378
(qty 1 per door)
Spacer, .385” ID X .574” OD X .040” Thk, SS 102725 (qty 4 per door)
6 Hinge, Right
HHD-8379
(qty 1 per door)
Spacer, .385” ID X .574” OD X .040” Thk, SS 102725 (qty 4 per door)
7 Weight, Door
HHD-8380
(qty 2 per door)
Screw, 1/4-20 X 1/2 Lg, HWH, Serr, SS 101394 (qty 2 per hinge)
