A-7
APPENDIX REPLACING OVEN COMPONENTS
Figure
Reference #
Item Description Item Part Number Fastener Description Fastener Part Number(s)
1 EMI Filter
100539
(qty 1 per cavity)
Screw, #8 X 1/2 Phil., Truss, Type 17, Serr, SS 101688 (qty 2 each)
2 Fuse Block
DL Config: 103566 (qty 2)
All Others: 103548 (qty 2)
Nut #6-32 Keps External Tooth SS 102961
3 Fuse, 12 amp, Class CC, ATMR
DL Config: 100592 (qty 3)
All others: 100592 (qty 2)
N/A N/A
4 Fuse, 30 amp, Class CC, ATMR
DL Config: 105196 (qty 3)
All others: None
N/A N/A
5 Heater, Kit
HHD-3003
(qty 1 per cavity)
Screw, #8 X 1/2 Phil., Truss, Type 17, Serr, SS 101688 (qty 6 each)
6 Interlock Switch
105022
(qty 1 per cavity)
Screw, RD SL, 8-32 x 1, M/S 18-8 101662 (qty 2 each)
7 Power Supply, 12 VDC
US: 105034
Intl: 105191
Screw, #6-32 x 1/2, PPH, Drill Point, Zinc 101687 (qty 2)
8 Power Supply, 24 VDC
US: 101213
Intl: 105190
Screw, #6-32 x 1/2, PPH, Drill Point, Zinc 101687 (qty 2)
9 Rack Motor, Kit with Mount
HHD-3012
(qty 1 per cavity)
Screw, #8 X 1/2 Phil., Truss, Type 17, Serr, SS 101688 (qty 2 each)
10 Relay, K1 (Upper Rack Motor) 101274 Screw, #6-32 x 1/2, PPH, Drill Point, Zinc 101687 (qty 2)
11 Relay, K2 (Bottom Rack Motor) 101274 Screw, #6-32 x 1/2, PPH, Drill Point, Zinc 101687 (qty 2)
12 Relay, K3 (Upper Cavity Lights) 101274 Screw, #6-32 x 1/2, PPH, Drill Point, Zinc 101687 (qty 2)
13 Relay, K4 (Lower Cavity Lights) 101274 Screw, #6-32 x 1/2, PPH, Drill Point, Zinc 101687 (qty 2)
14 Relay, K9 (Heaters) 101279 Screw, #8 X 1/2 Phil., Truss, Type 17, Serr, SS 101688 (qty 2)
15
Relay, Solid State, K5/K6
(Upper Heaters)
101286 Screw, #8 X 1/2 Phil., Truss, Type 17, Serr, SS 101688 (qty 2)
16
Relay, Solid State, K7/K8
(Lower Heaters)
101286 Screw, #8 X 1/2 Phil., Truss, Type 17, Serr, SS 101688 (qty 2)
17 RTD Temperature Sensor, 3.0”
HHC-6517-2
(qty 1 per cavity)
Screw, #8 X 1/2 Phil., Truss, Type 17, Serr, SS 101688 (qty 2 each)
18 Speaker CON-7038
Bracket, Speaker, Standoff
Screw, #6-32 x 1/2, PPH, Drill Point, Zinc
HHD-8497
101687 (qty 4)
19
Swing Arm Assembly, Kit with
Motor and Mount
HHD-3010
(qty 1 per cavity)
Bushing, 5/16, Flange Mount
Screw, #8 X 1/2 Phil., Truss, Type 17, Serr, SS
Included with Kit
20
Thermostat, Cooling Fan, EC,
120F
102086 (qty 2) Screw, #6-32 x 1/2, PPH, Drill Point, Zinc 101687 (qty 2 each)
21 Thermostat, High-Limit, 300C
102075
(qty 1 per cavity)
Screw, M4 x 0.7 x 8, PPHD, Int Tooth, SS 101672 (qty 2 each)
22 Voltage Sensor CON-3027
Nut, #6-32, Hex, SS
Screw, #6-32 x 1/4 LG, PPH, SS
Standoff, #6-32 x 1/2, M/F, Hex, Zinc
Included in kit
Not Shown Harness, Cooling Fans 1 HHD-8434 N/A N/A
Not Shown Harness, Cooling Fans 2 HHD-8436 N/A N/A
Not Shown Harness, Heater Wire HHD-8433 N/A N/A
Not Shown Harness, Line Voltage HHD-8431 N/A N/A
Not Shown Harness, Low Voltage HHD-8432 N/A N/A
Not Shown
Wire, Heater Fuse Terminal (DL
config only)
HHD-8437 (qty 3) N/A N/A
To Next Page
