TurboChef Double Batch User Manual

A-9
APPENDIX  REPLACING OVEN COMPONENTS
Figure
Reference #
Item Description Item Part Number Fastener Description Fastener Part Number(s)
1 Gasket, Display HHD-8447 N/A N/A
2 SAGE Control Board, Kit CON-3019-2
Screw, #6-32 x 1/4, SIM, Int Tooth, PPHD
Nut #6-32 Keps External Tooth SS
Bracket, Control Board Mounting, Top
Bracket, Control Board Mounting, Bottom
102910 (qty 4)
102961 (qty 4)
HHD-8493
HHD-8494
3 Touch Screen, Kit CON-3028-7
Washer, Lock, #6 EXT TH, CRES
Screw, #6-32 x 38 Lg, PPHD, SEMS, CRES
102270 (qty 4)
102911 (qty 4)
4 USB Socket 100419
Bracket, USB
Gasket, USB
Nut, Keps Hex, #6-32, EXT Tooth, CRES
HHD-8467
HHD-8448
102961 (qty 2)
Not Shown Cable, SAGE to Touch Display CON-7076 N/A N/A
Not Shown Cable, Speaker CON-7077 N/A N/A
Not Shown Cable, USB 100418 N/A N/A
Not Shown Cable, Display Power i1-9475 N/A N/A
