TurboChef Double Batch

A-11
APPENDIX  REPLACING OVEN COMPONENTS
Figure
Reference #
Item Description Item Part Number Fastener Description Fastener Part Number(s)
1 Air Filter HHD-8422 N/A N/A
2 Blower Motor
HHB-8106
(qty 1 per cavity)
Nut, 1/4-20, Serrated Hex Flange, Zinc 100906 (qty 5 each)
3 Blower Motor Speed Controller
CON-7013
(qty 1 per cavity)
Screw, #8 X 1/2 Phil., Truss, Type 17, Serr, SS
Screw, #8-18 x 3/8 PMTRH, CRES
101688 (qty 2 each)
101682 (qty 2 each)
4 Cooling Fan
US: 100516 (qty 4)
Intl: 105181 (qty 4)
Screw, #10 -32 x 1/2, Hex WSHR HD, Type 23 101408 (qty 4 each)
5 Cooling Fan Duct HHD-8475 Screw, #10 -32 x 1/2, Hex WSHR HD, Type 23 101408 (qty 2 each)
6 Finger Guard
US: 100087 (qty 4)
Intl:
Screw, #10 -32 x 1/2, Hex WSHR HD, Type 23 101408 (qty 4 each)
7 Vent Catalyst Cover
HHD-8477
(qty 1 per cavity)
Screw, #8-18 x 3/8 PMTRH, CRES 101682 (qty 2 each)
Not Shown
Power Cord, 60 Hz, 208-240
VAC, 1 PH, US
i5-9127 None None
Not Shown
Power Cord, 60 Hz, 208-240
VAC, 3 PH, US
i5-9128 None None
