turck TBEN-L 8IOL Series User Manual

V02.00 | 2019/10
103
VAUX Control Class (VSC 161)
This class contains parameters and diagnostics for the monitoring of 24 VDC sensor and actu-
ator supply.
Attr.-no. Designation Get/
Set
Type Meaning
Dec. Hex.
Activate VAUX1 monitoring
1 0x01 VAUX Control - VAUX1 pin1 C0 (ch0/1) G/S USINT 0 = 24 VDC
1 = switchable
2 = off
2 0x02 VAUX Control - VAUX1 pin1 C1 (ch2/3) G/S USINT 0 = 24 VDC
1 = switchable
2 = off
3 0x03 VAUX Control - VAUX1 pin1 C2 (ch4/5) G/S USINT 0 = 24 VDC
1 = switchable
2 = off
4 0x04 VAUX Control - VAUX1 pin1 C3 (ch6/7) G/S USINT 0 = 24 VDC
1 = switchable
2 = off
5 0x05 VAUX Control - VAUX1 pin1 C4 (ch8) G/S USINT 0 = 24 VDC
1 = switchable
2 = off
7 0x07 VAUX Control - VAUX1 pin1 C5 (ch10) G/S USINT 0 = 24 VDC
1 = switchable
2 = off
9 0x09 VAUX Control - VAUX1 pin1 C6 (ch12) G/S USINT 0 = 24 VDC
1 = switchable
2 = off
11 0x0B VAUX Control - VAUX1 pin1 C7 (ch14) G/S USINT 0 = 24 VDC
1 = switchable
2 = off
Activate VAUX1 monitoring
6 0x06 VAUX Control - VAUX2 pin2 C4 (ch9) G/S USINT 0 = 24 VDC
1 = switchable
2 = off
8 0x08 VAUX Control - VAUX2 pin2 C5 (ch11) G/S USINT 0 = 24 VDC
1 = switchable
2 = off
10 0x0A VAUX Control - VAUX2 pin2 C6 (ch13) G/S USINT 0 = 24 VDC
1 = switchable
2 = off
12 0x0C VAUX Control - VAUX2 pin2 C7 (ch15) G/S USINT 0 = 24 VDC
1 = switchable
2 = off
VAUX1 status
13 0x0D VAUX Control - VAUX1 pin1 C0 (ch0/1) G USINT 0 = off
1 = on
14 0x0E VAUX Control - VAUX1 pin1 C1 (ch2/3) G USINT 0 = off
1 = on
