15 Technical data
Technical Data
Power supply
Supply voltage 24 VDC
Permissible range 18…30 VDC
n IO-Link n 20,4 ... 28.8 VDC
Total current Max. 9 A per voltage group
V1 + V2 max. 11 A
Operating current < 120 mA
Sensor/actuator supply V
AUX1
Supply from V1 short-circuit proof,
max. 4 A per connector C0 und C4,
max. 2 A per connector C1…C3, C5…C7
Sensor/actuator supply V
AUX2
Class B supply from V2 short-circuit proof,
max. 4 A per connector C4…C5
max. 2 A per connector C6…C7
Potential isolation Galvanic isolation from V1 and V2 voltage group, voltages
up to 500 VDC
Connectors
Ethernet 2 x M12, 4-pin, D coded
Power supply
n TBEN-L4-… n X1: 7/8“ male connector, 4-pole
n X2: 7/8“ female connector, 4-pole
n TBEN-L5-… n X1: 7/8“ male connector, 5-pole
n X2: 7/8“ female connector, 5-pole
Digital in-/outputs
Permissible torques
n Ethernet
n I/O channels/supply
n Mounting (M6 screws)
0.6 Nm
0.8 Nm
1.5 Nm
Isolation voltages
V1 to V2 ≥ 500 V AC
V1/V2 to field bus ≥ 500 V AC
System data
Transmission rate 10 Mbps/100 Mbps
Fieldbus connection technology 2 x M12, 4-pole, D coded
Protocol detection Automatic
Web server Integrated, 192.168.1.254
Service interface Ethernet via P1 or P2
Field Logic Controller (FLC)
Supported from firmware version 3.0.6.0
Released as of ARGEE version 2.0.25.0
Modbus TCP
Address assignment Static IP, DHCP
Supported Function Codes FC1, FC2, FC3, FC4, FC5, FC6, FC15, FC16, FC23
Number of TCP connections 8
