8.10 Connecting the devices to a Rockwell PLC with EtherNet/IP™
Used Hardware
The following hardware components are used in this example:
n Rockwell PLC ControlLogix 1756-L72, Logix 5572
n Rockwell Scanner 1756-EN2TR
n Block module TBEN-L5-8IOL
Used Software
The following software tools are used in this example:
n Rockwell RS Logix
n Catalog file for Turck compact stations "TURCK_BLOCK_STATIONS_Vxx.L5K" as part of the file
"TBEN-L_ETHERNETIP.zip" (downloadable free of charge under www.turck.com)
Catalog files
Turck provides catalog files "TURCK_BLOCK_STATIONS_Vxx.L5K" for use in Rockwell Automa-
tion's RSLogix/Studio5000. The catalog files contain predefined, application-dependent device
configurations with different input and output data widths and descriptions of the configura-
tion, input and output tag data. The predefined device configurations correspond to the input
and output assembly instances described in the section "Assembly Object" in the chapter
"Commissioning Devices with EtherNet/IP™” Ò under "EtherNet/IP™ Standard Classes".
NOTE
The catalog file is available in the L5K file format and must be converted to the
"ACD" file format before it can be used. The file is opened in RSLogix/Studio5000
and saved as a project (*.ACD).
Prerequisites
n Instance of the programming software RSLogix/Studio5000 with the Catalog files is opened.
n A new project has been created in a second instance of RSLogix/Studio5000.
n The PLC and the Scanner mentioned above have been added to the project in the second in-
stance of RSLogix/Studio5000.
