Technical Data
Register start address 0 (0x0000)
Register start address 2048 (0x0800)
Lokal port Port 502, fixed setting
EtherNet/IP™
Address assignment according to EtherNet/IP™ standard
Device Level Ring (DLR) Supported
Quick Connect (QC) < 150 ms
Number of Class 3 (TCP) connec-
tions
3
Number of Class 1 (CIP) connec-
tions
10
Input Assembly Instances 103, 120, 121, 122, 123,124, 125
Output Assembly Instances 104, 150, 151, 152
Configuration Assembly Instance 106
PROFINET
PROFINET specification V 2.35
Conformance Class B (RT)
Address assignment DCP
MinCycle Time 1 ms
Fast Start-Up (FSU) < 150 ms
Diagnostics according to PROFINET Alarm Handling
Topology detection Supported
Automatic address setting Supported
Media Redundancy Protocol (MRP) Supported
System redundancy S2
Network load class 3
Digital inputs
Number of channels 4 DXP and 8 SIO
Input type PNP
Type of input diagnostics Channel diagnosis
Switching threshold EN 61131-2 type 3, PNP
Signal voltage, low level < 5 V
Signal voltage, high level > 11 V
Low level signal current < 1.5 mA
High-level signal current > 2 mA
Input delay 0.05 ms
Potential isolation Galvanic isolation to P1/P2, voltage proof up to 500 V AC
Digital outputs
Number of channels 4 DXP
Output type PNP
Type of output diagnostics Channel diagnostics
Output voltage 24 VDC from potential group
Output current per channel 2 A, short-circuit-proof
