Technical data
146
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Technical Data
Potential isolation Galvanic isolation to P1/P2, voltage proof up to 500 V AC
IO-Link
Number of channels 8
IO-Link Pin 4 operated in IO-Link mode
IO-Link specification Version 1.1
IO-Link port type Class A at C0…C3
Class B at C4…C7
Frame type Supports all specified frame types
Supported devices Max. 32 byte input/32 byte output
n Input data n max. 32 Byte per channel
n Output data n max. 32 Byte per channel
Transmission rate 4,8 kbps (COM 1)
38,4 kbps (COM 2)
230,4 kbps (COM 3)
Transmission cable Length: max. 20 m standard lines,
3- or 4-wire (depending on the application), unshielded
Mounting
Type of mounting Via 2 mounting holes, ∅ 6.3 mm
Mounting distance (device to
device)
≥ 50 mm
Valid for operation in ambient temperatures defined be-
low with sufficient ventilation and maximum load (hori-
zontal nominal position).
At ambient temperatures of < 30 °C, the devices can also
be mounted directly next to each other.
Standard/Directive conformity
Vibration test According to EN 60068-2-6
Acceleration Up to 20 g
Shock test According to EN 60068-2-27
Drop and topple According to IEC 60068-2-31/IEC 60068-2-32
Electro-magnetic compatibility According to EN 61131-2
Approvals and certificates CE, FCC
UL cond. cULus LISTED 21 W2, Encl.Type 1 IND.CONT.EQ.
General information
Dimensions (B × L × H) 64 × 230.4 × 39 mm
Operating temperature -40…+70 °C
Storage temperature -40…+85 °C
Operating height max. 5000 m
Protection class IP65/IP67/IP69K
MTTF 160 years acc. to SN 29500 (Ed. 99) 20 °C
Housing material PA6-GF30
Housing color Black
Material window Lexan
Material label Polycarbonate
Halogen-free Yes
