Tuttnauer 3545 - DRAWING OF ELECTRICAL SYSTEM OF TABLE AUTOCLAVE MODEL 1730 M

Page 56 of 63 Pages
Cat. No.
Description
1730 2340 2540 3545 3850 3870
SST bolt M4 x 12
BOL191-0140 BOL191-0140 BOL191-0140 BOL191-0140 BOL191-0140 BOL191-0140
SST bolt 4M x 8
BOL191-0158 BOL191-0158 BOL191-0158 BOL191-0158 BOL191-0158 BOL191-0158
Bushing for selector
valve
CMT240-0019 CMT240-0019 CMT240-0019 CMT240-0019 CMT240-0019 CMT240-0019
Microswitch D48X
ELE036-0012 ELE036-0012 ELE036-0012 ELE036-0012 ELE036-0012 ELE036-0012
Male connector 1/4 x 1/4
FIT100-0308 FIT100-0308 FIT100-0308 FIT100-0308 FIT100-0308 FIT100-0308
Male elbow 5/16 x 1/4
FIT100-0309 FIT100-0309 FIT100-0309 FIT100-0309 FIT100-0309 FIT100-0309
Brass nut 1/8
NUT192-0206 NUT192-0206 NUT192-0206 NUT192-0206 NUT192-0206 NUT192-0206
Star disk 1/8
NUT193-0290 NUT193-0290 NUT193-0290 NUT193-0290 NUT193-0290 NUT193-0290
Nut 3/8”
CMT240-0020 CMT240-0020 CMT240-0020 CMT240-0020 CMT240-0020 CMT240-0020
Screw 4M x 12
BOL191-0100 BOL191-0100 BOL191-0100 BOL191-0100 BOL191-0100 BOL191-0100
Below housing bolt
LOK240-0026 LOK240-0026 LOK240-0026 LOK240-0026 LOK240-0026 LOK240-0026
Safety membrane
housing
LOK240-0025 LOK240-0025 LOK240-0025 LOK240-0025 LOK240-0025 LOK240-0025
Membrane pin
L0K240-0023 L0K240-0023 L0K240-0023 L0K240-0023 L0K240-0023 L0K240-0023
Inner bushing for bellow
CMT067-0002 CMT067-0002 CMT067-0002 CMT067-0002 CMT067-0002 CMT067-0002
Metal sheet nut
4.8 x 1.25
NUT192-0230 NUT192-0230 NUT192-0230 NUT192-0230 NUT192-0230 NUT192-0230
Metal sheet nut
4.8 x 2-5
— NUT192-0236 NUT192-0236 NUT192-0236 NUT192-0236 NUT192-0236
Metal sheet screw
12 x 4.8
BOL194-0340 BOL194-0340 BOL194-0340 — — —
Metal sheet screw
10 x 3/4
— — — BOL194-0341 BOL194-0341 BOL194-0341
Switch, Pressure, B10,
Robert Show
THE005-0002 THE005-0002 THE005-0002 THE005-0002 THE005-0002 THE005-0002
