4. Slide the new endbell assembly onto the shaft as far as the brush retention clip
will permit.
5. Index the endbell wires to mark made in step #1. Align endbell to the slots in
the motor housing. Pull the brush retaining clip out while pressing the endbell
flushes to the motor housing.
6. Connect the black 115V (brown 230V) wire to the pump switch if applicable.
7. Install the motor assembly screws along with the green/yellow wire (115V
only). Torque to 12º18 m. lbs.
Perform Hi-Pot Test as follows:
1. The system conductors must be shorted
together, and all switches must be turned
―ON‖.
2. Hi-pot voltage is applied between the
shorted conductors and accessible dead
metal. The voltage frequency should be
within the range of 40-70 hertz.
3. Voltage should be applied in accordance
with either condition ―A‖ or condition ―B‖
per the table below.
