1.5 Symbol Description
Symbol
Description
Caution! Consult accompanying documents
Caution! Hot surface
Caution! Hot steam
Protective earth (Ground)
1.6 Utility Labels
Utility
Specification
Mineral Free Water
2–5 bar (30–70 psi)
Steam
3.5–4.5 bar (60–65 psi)
Tap Water
2–5 bar (30–70 psi)
Compressed Air
6–8 bar (85–115 psi)
Electricity
3 Ph, 208V/ 60Hz, 105 A
