4.2 Description of Displayed Messages and Safety Measures
03 - Manual Stop
This message is displayed and the FAIL indicator lights up
after the STOP key is pressed for more than 1 second during
the cycle (excluding the drying stage).
100 - Man. Stop
This message is displayed and the FAIL indicator lights up
after the STOP key is pressed for longer than one second in
the drying stage.
05 - Door Unlock
This message is displayed if either of the following occurs:
The START button is pressed and the door is not closed or
if during a cycle or the pressure drops in the gasket.
06 - Temp. Error
If the temperature sensor is disconnected for any reason
during the heating stage, temperature is either higher than
140ºC (284ºF) or lower than 5ºC (41ºF).
07 - Low Heat
This message is displayed and sterilization does not start if
the autoclave has not reached sterilization temperature after
heating for the maximum time as defined in the HEAT T.O.
parameter.
08 - Low Temp.
This message is displayed, fail indicator lights up and cycle is
aborted, if the temperature drops for more than 5 secs. below
the required sterilization temperature.
09 - High Temp.
This message is displayed, fail indicator lights up and
program is aborted: If the temperature rises by 3ºC (5ºF)
above the required sterilization temperature during the
sterilization cycle.
10 - Low Pres.
This message is displayed, fail indicator lights up and the
program is aborted if the pressure drops for more than 5 sec.
below the pressure correlated to the required sterilization
pressure.
11- High Pres.
This message is displayed, fail indicator lights up and the
program is aborted, if pressure rises above the pressure
correlated to the sterilization temperature by 3ºC (5ºF) for
more than 5 sec.
12 - Low Vacuum
This message is displayed if after 18 min. the system has not
reached at the Vac Dip1or Vac Dip2 values during the pre-
vacuum stage. It also appears if the Leak Test program fails.
13 - Jacket not Ready
This message is displayed if the START key was activated
before the jacket reached the desired pressure.
21 - Door1 Safe Switch
If, while closing, Door #1 of an automatic sliding door, the
door safety bar feels resistance, the door will open, and this
message will appear.
22 - Door2 Safe Switch
If, while closing, Door #2 of an automatic sliding door, the
door safety bar feels resistance, the door will open, and this
message will appear.
