23 - Door1 Gasket Low
Vacuum
This message indicates that during opening Door #1, you do
not achieve the proper vacuum in Gasket1.
24 - Door2 Gasket Low
Vacuum
If whilst opening Door #2 you do not achieve the proper
vacuum in Gasket2.
This message is a result of a safety mechanism indicating
that if during the pre-vacuum stage, drying stage, vac. test or
leak test it is revealed that the lower float switch in the
vacuum water reservoir is open for more than 1 second (so
there is no water entering the water reservoir and the pump
has therefore been closed to protect it).i.e. Vfloat –L = ―1‖
This message appears if there was an attempt to perform
IN/OUT Test while the door is open.
Informative Messages
This message appears on the panel during calibration.
When an automatic door is closing, this message is displayed
so that the operator waits until the closing operation of the
automatic door is completed.
When an automatic door is opening, this message is
displayed so that the operator waits until the opening
operation of the automatic door is completed.
This message appears when Door1 is open. It will also
appear if the door is supposedly closed but there is not
enough pressure in the gasket to seal it properly.
This message appears when Door2 is open. It will also
appear if the door is supposedly closed but there is not
enough pressure in the gasket to seal it properly.
This message appears when both doors are open.
This message appears on panel 2 during the IN/OUT Test
and during Setup.
