OPERATION
&
MAINTENANCE
MANUAL
Pre-Vacuum Steam Heated Autoclave
with one Vertical Sliding Door
and a 36 kW Steam Generator
Model 6671130 2VEP
S.N: 1102058
Cat. No.: MAN205-0195042EN Rev A Aug. 2011
Tuttnauer. Ltd., Har Tuv Industrial Zone, B P.O. Box 170, Beit Shemesh, 99000, Israel, Tel:972 2 9904611
Fax:972 2 9904730
Tuttnauer Europe b.v., Hoeksteen 11, 4815 PR Breda Breda, P.O. Box 7191, 4800 GD Breda, Netherlands.
+31/76-5423510, Fax: +31/76-5423540

Table of Contents

Questions and Answers

  • Q
    qbrooksAug 25, 2025
    How to fix a Tuttnauer Steriliser sliding door that won't open?
    • S
      Stephanie ClarkAug 25, 2025
      If the door of your Tuttnauer Steriliser (sliding doors) does not open, consider these possible causes: low pressure at the air supply line (set the correct air pressure, which has to be atmospheric pressure), insufficient vacuum to gasket due to trouble with the vacuum system, a gasket improperly seated or damaged (mount the gasket suitably or replace it), the OPEN DOOR solenoid valve transmitting air pressure to the door actuator is stuck or damaged (repair or replace the faulty valve), or a damaged door drive actuator (fix or replace actuator).
  • T
    Tammy BaileyAug 26, 2025
    Why won't the sliding door close on my Tuttnauer Steriliser?
    • K
      Kenneth SloanAug 26, 2025
      If the door on your Tuttnauer Steriliser (sliding doors) isn't closing, it could be due to several reasons. Check for low pressure at the air supply line and set the air pressure to 1.5 bar. The CLOSE DOOR solenoid valve, which transmits air pressure to the door actuator, might be stuck or damaged, requiring repair or replacement. A damaged door drive actuator could also be the cause, so consider fixing or replacing it. Additionally, ensure the OPEN DOOR button isn't defective; if it is, replace it. Finally, control system issues can prevent the door from closing, so replacing the control boards might be necessary.
  • B
    brobinsonAug 28, 2025
    What causes exhaust phases to malfunction on a Tuttnauer Steriliser?
    • P
      Patrick RamosAug 28, 2025
      If the fast or slow exhaust phases aren't working on your Tuttnauer Steriliser, resulting in high chamber pressure or a prolonged exhaust, here's what to check: The fast or slow exhaust valves might be stuck or damaged, requiring repair or replacement. A leaking steam valve can also cause this issue, so repair or replace the steam valve if necessary. Alternatively, there might be a control system problem, in which case you should replace the control boards.
  • K
    Katherine BanksAug 29, 2025
    Why is my Tuttnauer Steriliser sliding door not sealing?
    • W
      Wayne WrightAug 30, 2025
      If the door on your Tuttnauer Steriliser (sliding doors) is not sealing properly, consider these possible causes: low pressure at the air supply (set the air pressure to 1.5 bar), low steam pressure at the door gasket (set the steam pressure to 1.5 bar), a blocked or damaged pressure to gasket pneumatic valve (fix or replace the pneumatic valve), stuck or damaged solenoid or pneumatic valves controlling the pressure or vacuum to the gasket (repair or replace the defective valve), or a control system issue (replace the control boards).
  • K
    kevin13Aug 31, 2025
    Why is the temperature too high in my Tuttnauer Steriliser?
    • D
      deborahwilliamsSep 1, 2025
      If the temperature rises above the preset sterilization value in your Tuttnauer Steriliser, it could be due to a few reasons: The steam pressure might be too high, so check and correctly set the pressure switch of the generator and the pressure reducer. A leaking steam valve can also cause this issue, so fix or replace the steam valve. Alternatively, there might be a control system problem, in which case you should replace control boards.
  • L
    Lawrence MillerSep 2, 2025
    Why is the drying stage not working on my Tuttnauer Steriliser?
    • G
      Gabriel LongSep 2, 2025
      If the drying stage isn't working on your Tuttnauer Steriliser, consider the following potential causes: there may be trouble with the vacuum system, a leaking steam valve, or a control system issue. If it's a vacuum problem, you should consult related sections for troubleshooting. For a leaking steam valve, repair or replace it. If the issue stems from the control system, consider replacing the control boards.
  • M
    Melissa HernandezSep 4, 2025
    What causes excessive steam pressure in a Tuttnauer Steriliser?
    • A
      andrew30Sep 4, 2025
      If the steam pressure in your Tuttnauer Steriliser increases beyond the control point, it could be due to a faulty or incorrectly set pressure switch (check, repair, or replace the pressure switch). Alternatively, the contacts at the contactor might be welded because of a short circuit (check the cause and replace the damaged contactor).
  • J
    Jennifer CobbSep 6, 2025
    Why is the temperature and pressure low in my Tuttnauer Steriliser after the pre-vacuum phase?
    • D
      Daniel HendersonSep 6, 2025
      If the pre-vacuum phase completes but the temperature and pressure remain low, preventing the sterilization point from being reached quickly in your Tuttnauer Steriliser, several factors could be responsible: low pressure at the steam supply line or a clogged or damaged steam inlet valve (check the steam generator, fix the pressure, and check, fix, or replace the steam valve). Another possible cause is faulty or incorrectly set electronic pressure transducers or measuring circuits (set them correctly or replace boards). Control system issues might also be the cause, requiring replacement of the control boards.
  • M
    Mary AlexanderSep 8, 2025
    Why am I getting unsatisfactory sterilization results from my Tuttnauer Steriliser?
    • W
      wandasparksSep 8, 2025
      If you're getting unsatisfactory sterilization results with your Tuttnauer Steriliser, it could be due to a few reasons: incomplete removal of air pockets, improper sterilization conditions (temperature or pressure too low, time too short), or incorrect loading of the autoclave, leading to trapped air in the load. Ensure the correct temperature and time are set according to the material, and consult the relevant section on preparation before sterilization.
  • J
    Joseph DavisSep 12, 2025
    Why are packs still wet after drying in my Tuttnauer Steriliser?
    • C
      cynthiasimpsonSep 12, 2025
      If packs remain wet after the drying cycle in your Tuttnauer Steriliser, it could be due to several factors: insufficient steam pressure to the jacket (set or fix the pressure switch), insufficient vacuum, a steam trap that doesn't eliminate the condensate (clean or repair the steam trap), or incorrect loading of the autoclave (reload the autoclave appropriately).
