TVS XL Series User Manual

It is recommended to use the tool kit in case of any
emergency only. It is always advisable to take your
vehicle to TVS Motor Company Authorised
Distributor or Dealer / Authorised Service Centers.
Note
KNOW YOUR TVS XL 100
SMART PHONE CHARGER**
A smart phone charger has been provided in your
vehicle for charging your smart phone even when you
are traveling and it is located in the cowl of
speedometer. Follow the guidelines given below to
use the charger properly.
DO’s
1. Ensure that no water enters into the USB charging
unit by closing the flap properly and by avoiding
the direct water jet towards the unit.
2. Use the USB chager only with standard approved
USB charging cable recommended for your smart
phone.
3. Do make sure the flap is not damaged while
opening / inserting the USB cable.
DON’TS
1. Do not leave the USB charging flap open / partially
closed.
2. Do not attempt to use / charge any other device,
other than smart phone phones. Only one smart
phone should be charged at a given time.
3. Do not try to force the USB connector in, check
whether it is inserted in the appropriate direction,
to prevent the damage to the charger.
4. Do not charge your smart phone when engine is
off.
-14-
** Applicable for ‘i-Touch Start’ models only
KNOW YOUR TVS XL 100

TVS XL Series Specifications

General

Displacement	99.7 cc
Maximum Torque	6.5 Nm @ 3500 rpm
Fuel System	Carburetor
Front Brake	Drum
Rear Brake	Drum
Starting Method	Kick Start
Engine Type	Single Cylinder, 4-Stroke
Front Suspension	Telescopic
Rear Suspension	Swing Arm with Hydraulic Shock Absorber
Fuel Tank Capacity	4 liters
Kerb Weight	80 kg
Wheel Type	Spoke
Tyre Type	Tube
Front Tyre Size	2.50 - 16
Rear Tyre Size	2.50 - 16
Seat Height	770 mm
Ground Clearance	150 mm
Transmission	Single Speed Gearless
