MANUFACTURER : TVS MOTOR COMPANY LIMITED
P.B. No. 4, Harita, Hosur - 635 109, India.
ENGINE
Type : Single cylinder, 4 stroke, air
cooled spark ignition engine
Cylinder bore : 51 mm
Stroke : 48.8 mm
Piston displacement : 99.7 cc
Compression ratio : 9.7 : 1
Carburettor : SPACO AU
Air filter : Paper filter element
Lubrication system : Forced lubrication
Maximum power in kW : 3.2 kW (4.3 bhp) @ 6000 rpm
Maximum torque in Nm : 6.5 Nm @ 3500 rpm
Maximum speed : Around 62 km/h (XL 100,
XL 100 i-Touch start, XL 100
Comfort STD)
: Around 58 km/h (XL 100
Heavy Duty, XL 100 Heavy Duty
i-Touch start)
Engine idling rpm : 1550 ± 100 rpm (under
warm condition)
Starting system : Kick starter / Electric start**
Emission norms : BS IV
TRANSMISSION
Clutch : Centrifugal shoe type wet clutch
Primary transmission : Single speed gear box
Secondary transmission : Chain and sprockets
Final reduction : 12.66 : 1 (XL100, XL 100 Comfort STD)
: 13.87 : 1 (XL100 Heavy Duty)
CHASSIS
Overall length : 1895 mm
Overall width : 670 mm
Overall height : 1077 mm
Ground clearance : 145 mm
Wheel base : 1228 mm
Kerb weight (with toolkit
and 90% of fuel) : 80 kg (XL 100, XL 100 Comfort STD)
: 84 kg (XL 100 Heavy Duty)
: 86 kg (XL 100 i-Touch start)
: 87 kg (XL 100 Heavy Duty i-Touch start)
Pay load : 130 kg
TECHNICAL SPECIFICATION
-38-
** Applicable for ‘i-Touch Start’ models only
TECHNICAL SPECIFICATION

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TVS XL Series and is the answer not in the manual?

TVS XL Series Specifications

General IconGeneral
Displacement99.7 cc
Maximum Torque6.5 Nm @ 3500 rpm
Fuel SystemCarburetor
Front BrakeDrum
Rear BrakeDrum
Starting MethodKick Start
Engine TypeSingle Cylinder, 4-Stroke
Front SuspensionTelescopic
Rear SuspensionSwing Arm with Hydraulic Shock Absorber
Fuel Tank Capacity4 liters
Kerb Weight80 kg
Wheel TypeSpoke
Tyre TypeTube
Front Tyre Size2.50 - 16
Rear Tyre Size2.50 - 16
Seat Height770 mm
Ground Clearance150 mm
TransmissionSingle Speed Gearless
