TVS XL Series User Manual

TYRES
Tyre pressure
Check the tyre pressure atleast once in a week if
not more frequently. Insufficient air pressure in the
tyres not only hasten tyre wear, but also seriously
affects the stability of the vehicle.
Under inflated tyres make smooth cornering
difficult and over inflated tyres decrease the tyre
contact with the ground which can lead to skidding
and loss of control. Be sure that the tyre pressure is
within the specified limits at all times.
Solo Dual
Front 1.75 kg/cm² (25 PSI) 1.75 kg/cm² (25 PSI)
Rear 2.46 kg/cm² (35 PSI) 2.81 kg/cm² (40 PSI)
Tyre tread condition
Operating the vehicle with excessively worn tyres
will decrease riding stability and can lead to loss of
control. It is recommended to replace the tyre
when the tyre wears off to the tyre wear indicator
(A) level (indicated by TWI on the tyre).
Warning
The tyre inflation pressure in cold condition and the
tyre tread condition are extremely important for the
performance and safety of the rider. Check the
tyres frequently for inflation pressure as well as the
wear pattern on it.
Use of a tyre other than the standard may cause
instability.
TWI
A
MAINTENANCE
-31-
MAINTENANCE

TVS XL Series Specifications

General

Displacement	99.7 cc
Maximum Torque	6.5 Nm @ 3500 rpm
Fuel System	Carburetor
Front Brake	Drum
Rear Brake	Drum
Starting Method	Kick Start
Engine Type	Single Cylinder, 4-Stroke
Front Suspension	Telescopic
Rear Suspension	Swing Arm with Hydraulic Shock Absorber
Fuel Tank Capacity	4 liters
Kerb Weight	80 kg
Wheel Type	Spoke
Tyre Type	Tube
Front Tyre Size	2.50 - 16
Rear Tyre Size	2.50 - 16
Seat Height	770 mm
Ground Clearance	150 mm
Transmission	Single Speed Gearless
