TVS XL Series User Manual

CHASSIS
Maximum laden weight : 210 kg (XL 100, XL 100 Comfort
STD)
: 214 kg (XL 100 Heavy Duty)
: 216 kg (XL 100 i-Touch start)
: 217 kg (XL 100 Heavy Duty i-Touch
start)
Frame : Welded tubular step through
construction
Front suspension : Telescopic spring type
Rear suspension : Swing arm fitted with hydraulic
shock absorbers with variable
rated spring.
TYRE
Tyre size
Front : 2.50-16 - 6 PR 41L
Rear : 2.50-16 - 6 PR 41L
Tyre pressure
2
Front : 1.75 kg/cm (25 PSI)
2
Rear - solo : 2.46 kg/cm (35 PSI)
2
Rear - dual : 2.81 kg/cm (40 PSI)
BRAKES
Front : Hand operated, internally
expanding shoe type 80 mm
dia. drum
Rear : Hand operated, internally
e x p a n d i n g s h o e t y p e
110 mm dia. drum
ELECTRICAL
Type : AC generator
Ignition system : Electronic Ignition (pulsar
type) IDI cum IG Coil :
Control unit ISG**
Spark plug : B O S C H U R 5 K C /
CHAMPION RG8MC
Spark plug gap : 0.6 ~ 0.7 mm
Battery type : ** 12V, 3 Ah MF battery
Body earthing : Negative terminal
Head lamp : 12V, 35/35W x 1
DRL : 12V, LED
Tail / brake lamp : 12V, 5/21W x 1
Turn signal lamp : 12V, 10W x 4
Speedometer lamp : 12V, 3.4W x 1
High beam indicator lamp : 12V, 2W x 1
Turn signal indicator lamp : 12V, 2W x 1
TECHNICAL SPECIFICATION
-39-
** Applicable for ‘i-Touch Start’ models only
TECHNICAL SPECIFICATION

TVS XL Series Specifications

General

Displacement	99.7 cc
Maximum Torque	6.5 Nm @ 3500 rpm
Fuel System	Carburetor
Front Brake	Drum
Rear Brake	Drum
Starting Method	Kick Start
Engine Type	Single Cylinder, 4-Stroke
Front Suspension	Telescopic
Rear Suspension	Swing Arm with Hydraulic Shock Absorber
Fuel Tank Capacity	4 liters
Kerb Weight	80 kg
Wheel Type	Spoke
Tyre Type	Tube
Front Tyre Size	2.50 - 16
Rear Tyre Size	2.50 - 16
Seat Height	770 mm
Ground Clearance	150 mm
Transmission	Single Speed Gearless
