92
Jumpers & Connectors
Connectors
1. ID LED Button / ID LED (IDLED_BTN1)
22. 4-pin HDD Backplane Power Connector
(D4P_PW3)
2. RJ45 LAN Port (LAN3) (IPMI) 23. CPU1 PWR OK LED (P1_PG_LED1)
3. RJ45 LAN Port (LAN2) 24. 4-pin Fan Connector (CPU1_FAN)
4. RJ45 LAN Port (LAN1) 25. CPU0 PWR OK LED (P0_PG_LED1)
5. BMC Heartbeat LED (BMC_LED1) 26. 4-pin Fan Connector (CPU0_FAN)
6. BIOS Socket (BIOS_SOCKET1)
27. 7-pin Vertical SATA3.0 Connector
(SATA) (PCH_SSATA_5)
7. TYAN Module Header (DBG_HD1)
28. 7-pin Vertical SATA3.0 Connector
(SATA) (PCH_SSATA_4)
8. Reset Button (RST_BTN1)
29. 4-pin HDD Backplane Power Connector
(D4P_PW1)
9. Power Button (PWR_BTN1) 30. PSU12V Power Connector (J45)
10. Platform RESET OK LED
(SYS_RST_LED1)
31. PCH AUX PWR OK LED
(PCH_PWOK_LED1)
11. ATX PWR OK LED (ATX_PG_LED1)
32. Onboard HDD Active LED
(HDD_LED1)
12. FAN Header for BP FAN Board (J29) 33. AST2500 (BMC1)
13. Vertical Type-A USB3.0 Connector
(USB1)
34. Onboard BMC IPMI alert LED
(IPMI_LED1)
14. IPMB Pin Header (IPMB_HD1) 35. BMC Socket (BMC_SOCKET1)
15. PCH sSATA SGPIO Header for HDD
Backplane (SSATA_SGPIO1)
36. CPU Error LED (ERR_LED1)
16. Battery Socket (CR1) 37. CATERR LED (CAT_LED1)
17. VGA Header (FPIO_VGA1) 38. USB3.0 Header (USB3)
18. Front Panel Header (FPIO_1)
39. Mini SAS HD Connector (SATA/SAS
signals) (PCH_SSATA_03)
19. COM1 Header (COM1)
40. Mini SAS HD Connector (SATA/SAS
signals) (PCH_SSATA_47)
20. Intel VROC Key Header (J47)
41. Mini SAS HD Connector (SATA/SAS
signals) (PCH_SSATA_03)
21. 4-pin HDD Backplane Power Connector
(D4P_PW2)
Jumpers
a ME Recovery Mode Jumper (J38) d/e LPC Mode Header (J37/J41)
b/c BMC CONSOLE PORT5 Jumper
(J34/J36)
f Clear CMOS Header (J44)
