93
Slots
A PCI-E 3.0x16 slot (J3)
B/C/D/E/F/G/H/I PCI-E3.0x16 slot
(x16 link:S7109GM2NR-2T)
(x8 link:S7109GM2NR-8X-2T)
(J8/J9/J10/J11/J12/J13/J14/J15)
R PCI-E 3.0x8 slot (open-end type,
J25)
J/K/L/M/N/O/P/Q PCI-E 3.0x8 slot
(x8 link, open-end type, only for
S7109GM2NR-8X-2T)
(J16/J17/J18/J19/J20/J21/J22/J23)
S PCI-E 3.0x8 slot (open-end type)
(J48, only for Tyan riser card)
Jumper Legend
OPEN - Jumper OFF Without jumper cover
CLOSED - Jumper ON With jumper cover
