196
Status Code
Description
0xE3
OS S3 wake vector call
0xE4 – 0xE7
Reserved for future AMI progress codes
S3 Resume Error Codes
0xE8
S3 Resume failed
0xE9
S3 Resume PPI not found
0xEA
S3 Resume Boot Script error
0xEB
S3 OS wake error
0xEC – 0xEF
Reserved for future AMI error codes
Recovery Progress Codes
0xF0
Recovery condition triggered by firmware (Auto recovery)
0xF1
Recovery condition triggered by user (forced recovery)
0xF2
Recovery process started
0xF3
Recovery firmware image is found.
0xF4
Recovery firmware image is loaded.
0xF5 – 0xF7
Reserved for future AMI progress codes
Recovery Error Codes
0xF8
Recovery PPI is not available.
0xF9
Recovery capsule is not found.
0xFA
Invalid recovery capsule
0xFB – 0xFF
Reserved for future AMI error codes
PEI Beep Codes
# of Beeps
Description
Progress Codes
1
Memory not installed
1
Memory was installed twice (installPEIMemory routine in PEI
Core called twice).
2
Recovery started
